    Cream Polyester Tape 854 is an opaque, cream colored polyester tape with excellent chemical resistance for precious metal plating, especially gold.

    • Excellent chemical resistance in precious metal plating, especially gold
    • Polyester backing helps reduce failure from backing breakdown and shrinkage
    • Flexible backing helps reduce failure from cracking
    • Synthetic adhesive helps reduce failure from splice slippage because of good chemical resistance
    • Excellent results in sodium hydroxide etching of aluminum
    • Polyethylene tape core instead of cardboard

    Specifications

     Adhesion to Stainless‎  55 oz/in‎
     Adhesion to Stainless (metric)‎  6.0 N/cm‎ ,  1.6 kg/25.4 mm‎
     Adhesive Type‎  Synthetic Rubber‎
     Application Category‎  Protection‎
     Applications‎  Solder Masking Tape‎
     Backing‎  Polyester (PET)‎
     Color‎  Ten colors
     Performance Features‎  Chemical Resistant‎, Anti-Erosion in Electrolyte, No Adhesive Residue‎
     Primary Liner‎  None‎
     Product Form‎  Roll‎
     Product Series‎  854‎
     Temperature Range (Celsius)‎  - 50 Degree C to 150 Degree C‎
     Temperature Range (Fahrenheit)‎  - 58 Degree F to 302 Degree F‎
     Tensile Strength at Break‎  28 lb/in‎
     Tensile Strength at Break (metric)‎  509 N/100mm‎
     Total Tape Thickness without Liner‎  2.56 mil‎
     Total Tape Thickness without Liner (metric)‎  0.065 mm‎
     Total Thickness‎  2.56 mil‎
     Total Thickness (metric)‎  0.065 mm‎

    Product Disclaimer

    • The technical information and data shown on this page should be considered representative or typical only and should not be used for specification purposes.
    • 3M products shown on this website may not be available in all geographic regions or may not be available at this time. Please contact us to determine product availability.We can customized any size and die cutting our products for your specific needs.
